| SL.No. |
Parameter |
Specification |
| 1 |
Purification capacity |
12-15* Litres per hour * |
| 2 |
Max Duty Cycle |
120 liters per Day |
| 3 |
Storage Tank Capacity |
10 Litres |
| 4 |
10 stages Purification . |
- Pre-Candle,
- Antiscalant balls,
- Sediment Cartridge,
- Activated Carbon,
- RO,
- UF,
- UV System,
- TDS Minimiser,
- Mineral Cartridge ,
- Magnetic Softener
|
| 5 |
RO Membrane |
1812-75 GPD |
| 6 |
UV Lamp Power |
11 Watt |
| 7 |
Minimum Inlet Water Pressure |
0.3 kg/sq cm |
| 8 |
Maximum Inlet water Pressure |
2 kg/sq cm ( if input water pressure is more than 2kg/sq cm , install PRV before the Unit) |
| 9 |
Input Voltage |
160-300V AC ( 50Hz) |
| 10 |
Operating Voltage |
24V DC |
| 11 |
Input water Temperature |
Min 5 Celsius & Max 50 Celsius |
| 12 |
Total Dissolved Solids (TDS) |
Up to 2000 ppm |
| 13 |
Total Hardness |
600 ppm (max) |
| 14 |
Rejection of TDS |
Up to 95% |
| 15 |
Recovery |
Up to 25% |
| 16 |
Dimensions (mm) |
L 415 W 265 H 524 |
| 17 |
Net Weight |
9.5 kgs. |
| 18 |
Power rating |
40W |
